Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351C Cleveland |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.030 Bore, 1.300 CD, 0.912 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.030 in. Bore, 1.300 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_TLE |
Ford 351 Cleveland, 4.030 Bore, Dish, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Title |
SRP - Ford, Small Block, 4.030 in. Bore, Piston Kit |
| Compression Height |
1.300 |
| Engine - Web |
Small Block |
| Product Market |
Domestic |
| Make |
FORD |
| Piston Pin Outside Diameter |
0.912 |
| Oil Ring Thickness |
0.218 |
| Forging Type |
FSR |
| Wrist Pin Wall Thickness |
0.140 |
| Industry |
Automotive |
| Piston Pin Wall Thickness |
0.140 |
| Engine Type |
ICE |
| Product Type |
Engine Piston Kit |
| Piston Material |
4032 |
| Wrist Pin Outer Diameter |
0.912 |
| Add-On |
927-042-CS |
| Piston Head Type |
Dish |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Material |
5115 |
| Add-On |
S100S8-4030-5 |
| Prop 65 Yes/No |
Yes |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.030 in. Bore - 1.300 in. CH, -16.00 CC |
| Bore Diameter |
4.030 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Top Compression Ring Thickness |
0.0640 |
| Piston Series |
SRP |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0640 |
| Piston Volume |
-16.00 |
| Add-On |
912-2750-14-51S |
| Make - Web |
Ford |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ringset Included |
No |
| Cylinder Head |
CLEVELAND |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
