Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351C Cleveland |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.020 Bore, 1.300 CD, 0.912 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.020 in. Bore, 1.300 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 351 Cleveland, 4.020 Bore, Dish, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.020 in. Bore - 1.300 in. CH, -16.00 CC |
| Add-On |
S100S8-4020-5 |
| Industry |
Automotive |
| Add-On |
927-042-CS |
| Add-On |
912-2750-14-51S |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
473 |
| Top Compression Ring Thickness |
0.0640 |
| Piston Material |
4032 |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Cylinder Head |
CLEVELAND |
| Second Compression Ring Thickness |
0.0640 |
| Bore Diameter |
4.020 |
| Piston Volume |
-16.00 |
| Piston Pin Outside Diameter |
0.912 |
| Product Type |
Engine Piston Kit |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Make - Web |
Ford |
| Wrist Pin Length |
2.750 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Oil Ring Thickness |
0.218 |
| Prop 65 (C, R or CR) |
CR |
| Forging Type |
FSR |
| Piston Head Type |
Dish |
| Prop 65 Yes/No |
Yes |
| Engine |
Small Block |
| Piston Pin Material |
5115 |
| Title |
SRP - Ford, Small Block, 4.020 in. Bore, Piston Kit |
| Piston Pin Length |
2.750 |
| Ringset Included |
No |
| Wrist Pin Outer Diameter |
0.912 |
| Engine - Web |
Small Block |
| Compression Height |
1.300 |
| Piston Series |
SRP |
| Make |
FORD |
| Piston Pin Wall Thickness |
0.140 |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.140 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
