Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.060 Bore, 1.165 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.060 in. Bore, 1.165 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 302, 4.060 Bore, Dome, Set of 8 |
| Product Market |
Domestic |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Ringset Included |
No |
| Forging Type |
FSR |
| Piston Head Type |
Dome |
| Piston Pin Material |
5115 |
| Compression Height |
1.165 |
| Engine Type |
ICE |
| Title |
SRP - Ford, Small Block, 4.060 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.218 |
| Make |
FORD |
| Piston Pin Outside Diameter |
0.927 |
| Piston Series |
SRP |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Small Block |
| Wrist Pin Outer Diameter |
0.927 |
| Product Type |
Engine Piston Kit |
| Add-On |
927-042-CS |
| Piston Volume |
9.00 |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
927-2750-15-51S |
| Out of Stock Message |
Call for Availability |
| Add-On |
S100S8-4060-5 |
| Bore Diameter |
4.060 |
| Piston Material |
2618 |
| Make - Web |
Ford |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Second Compression Ring Thickness |
0.0640 |
| Piston Average Weight |
465 |
| Top Compression Ring Thickness |
0.0640 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.060 in. Bore - 1.165 in. CH, 9.00 CC |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
No |
| Wrist Pin Length |
2.750 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
