Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Dome, 4.040 Bore, 1.100 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.040 in. Bore, 1.100 CD, Dome, 8 Cyl. Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 302, 4.040 Bore, Dome, Set of 8 |
| Product Type |
Engine Piston Kit |
| Piston Material |
4032 |
| Wrist Pin Length |
2.750 |
| Prop 65 Yes/No |
Yes |
| Bore Diameter |
4.040 |
| Ring Set Included |
No |
| Second Compression Ring Thickness |
0.0640 |
| Piston Volume |
9.00 |
| Add-On |
927-2750-15-51S |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Add-On |
S100S8-4040-5 |
| Top Compression Ring Thickness |
0.0640 |
| Industry |
Automotive |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Prop 65 (C, R or CR) |
CR |
| Piston Average Weight |
451 |
| Out of Stock Message |
Call for Availability |
| Add-On |
927-042-CS |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Title |
SRP - Ford, Small Block, 4.040 in. Bore, Piston Kit |
| Piston Series |
SRP |
| Oil Ring Thickness |
0.218 |
| Engine |
Small Block |
| Forging Type |
FSR |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.040 in. Bore - 1.100 in. CH, 9.00 CC |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Ringset Included |
No |
| Product Market |
Domestic |
| Compression Height |
1.100 |
| Piston Pin Length |
2.750 |
| Piston Head Type |
Dome |
| Piston Pin Outside Diameter |
0.927 |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Make |
FORD |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
