As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
BMW M3 S50B32 EURO |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.425 Bore, 1.271 CD, 0.827 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, BMW, S50B32 Euro, 3.425 in. Bore, 11.50:1, Dome, 6 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
BMW S50B32 3.2L, 87.00 Bore, Dome, Set of 6 |
| Engine Type |
ICE |
| Piston Pin Outside Diameter |
0.827 |
| Wrist Pin Outer Diameter |
0.827 |
| Piston Series |
JE Pistons |
| Make |
BMW |
| Product Market |
European |
| Piston Pin Wall Thickness |
0.150 |
| Piston Head Type |
Dome |
| Compression Height |
1.271 |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Engine |
S50B32 EURO |
| Engine - Web |
S50B32 Euro |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Length |
2.250 |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Bore Diameter |
87.00 |
| Piston Quantity |
6 |
| Piston Volume |
-10.10 |
| Title |
JE Pistons - BMW, S50B32 Euro, 87.00 mm Bore, Piston Kit |
| Cylinder Head |
S50B32 EURO |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Title - Web |
JE Pistons BMW S50B32 Euro Piston Kit - 87.00 mm Bore - 1.271 in. CH, -10.10 CC |
| Piston Material |
2618 |
| Top Compression Ring Thickness |
0.0400 |
| Second Compression Ring Thickness |
0.0480 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Add-On |
JG1001-3425 |
| Out of Stock Message |
Call for Availability |
| Add-On |
827-2250-15-51C |
| Add-On |
827-063-MW |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Make - Web |
BMW |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
7.0000 |
