As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
BMW M3 S50B32 EURO |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.425 Bore, 1.271 CD, 0.827 Pin, Set of 6. |
| Description_EXT |
JE, BMW, S50B32 Euro, 3.425 in. Bore, 9.00:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
BMW S50B32 3.2L, 87.00 Bore, Dish, Set of 6 |
| Title - Web |
JE Pistons BMW S50B32 Euro Piston Kit - 87.00 mm Bore - 1.271 in. CH, -26.00 CC |
| Add-On |
827-2250-15-51C |
| Add-On |
827-063-MW |
| Cylinder Head |
S50B32 EURO |
| Industry |
Automotive |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
JG1001-3425 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Engine |
S50B32 EURO |
| Piston Pin Length |
2.250 |
| Prop 65 Yes/No |
Yes |
| Ringset Included |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Dish |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
BMW |
| Make |
BMW |
| Compression Height |
1.271 |
| Forging Type |
FSR |
| Title |
JE Pistons - BMW, S50B32 Euro, 87.00 mm Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.827 |
| Oil Ring Thickness |
0.111 |
| Piston Volume |
-26.00 |
| Piston Quantity |
6 |
| Product Type |
Engine Piston Kit |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
S50B32 Euro |
| Wrist Pin Outer Diameter |
0.827 |
| Piston Series |
JE Pistons |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Product Market |
European |
| Bore Diameter |
87.00 |
| Top Compression Ring Thickness |
0.0400 |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
