As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan RB26 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 3.386 Bore, 1.185 CD, 0.827 Pin, Set of 1. |
| Description_EXT |
JE, Nissan, RB Series, 3.386 in. Bore, 8.20:1, Dome, Single Piston |
| Description_INV |
JE Pistons, Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Nissan RB26, 86.00 Bore, Dome, Set of 1 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Material |
2618 |
| Add-On |
827-063-MW |
| Cylinder Head |
RB26DETT |
| Industry |
Automotive |
| Add-On |
827-2250-15-51C |
| Add-On |
JG2804-3386 |
| Make - Web |
Nissan |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Second Compression Ring Thickness |
0.0600 |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Dome |
| Title - Web |
JE Pistons Nissan RB Series Piston - 86.00 mm Bore - 1.185 in. CH, 15.30 CC |
| Piston Pin Length |
2.250 |
| Prop 65 Yes/No |
Yes |
| Engine |
RB SERIES |
| Ringset Included |
Yes |
| Piston Series |
JE Pistons |
| Top Compression Ring Thickness |
0.0480 |
| Make |
NISSAN |
| Prop 65 (C, R or CR) |
CR |
| Product Market |
Sport Compact |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.119 |
| Product Type |
Engine Piston |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.827 |
| Engine - Web |
RB Series |
| Ring Set Included |
Yes |
| Bore Diameter |
86.00 |
| Compression Height |
1.185 |
| Piston Quantity |
1 |
| Engine Type |
ICE |
| Forging Type |
Round |
| Piston Volume |
15.30 |
| Title |
JE Pistons - Nissan, RB Series, 86.00 mm Bore, Piston |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.827 |
| Wrist Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
