As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet LT1 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.065 Bore, 1.115 CD, 0.927 Pin, Set of 8. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_EXT |
JE, Chevrolet, LT1 Gen V, 4.065 in. Bore, 1.115 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet LT1, 4.065 Bore, Dome, Set of 8 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
4.065 |
| Title |
JE Pistons - Chevrolet, LT1 Gen V, 4.065 in. Bore, Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Wrist Pin Outer Diameter |
0.927 |
| Piston Average Weight |
455 |
| Piston Volume |
-4.60 |
| Piston Quantity |
8 |
| Product Type |
Engine Piston Kit |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Top Compression Ring Thickness |
0.0480 |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.149 |
| Compression Height |
1.115 |
| Make |
CHEVROLET |
| Engine - Web |
LT1 Gen V |
| Cylinder Head |
GEN 5 LT1 |
| Piston Pin Material |
5115 |
| Out of Stock Message |
Call for Availability |
| Add-On |
927-073-MW |
| Prop 65 Yes/No |
Yes |
| Title - Web |
JE Pistons Chevrolet LT1 Gen V Piston Kit - 4.065 in. Bore - 1.115 in. CH, -4.60 CC |
| Piston Head Type |
Dome |
| Piston Pin Outside Diameter |
0.927 |
| Add-On |
JG31F1-4070-0 |
| Piston Material |
2618 |
| Add-On |
927-2250-15-51C |
| Industry |
Automotive |
| Engine Type |
ICE |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Second Compression Ring Thickness |
0.0600 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.250 |
| Engine |
LT1 Gen V |
| Ringset Included |
No |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
