As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 4.135 Bore, 1.425 CD, 0.927 Pin, Set of 1. |
| Description_EXT |
JE, Chevrolet, Small Block Chevrolet, 4.135 in. Bore, 1.425 CD, Inverted Dome/Dish, Single Piston |
| Description_INV |
JE Pistons, Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 400, 4.135 Bore, Dish, Set of 1 |
| Description_SHO |
Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Ringset Included |
No |
| Engine |
Small Block |
| Piston Pin Length |
2.950 |
| Piston Series |
JE Pistons |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.188 |
| Forging Type |
Round |
| Title |
JE Pistons - Chevrolet, Small Block, 4.135 in. Bore, Piston |
| Piston Head Type |
Dish |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0640 |
| Engine Type |
ICE |
| Make |
CHEVROLET |
| Compression Height |
1.425 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Engine - Web |
Small Block |
| Wrist Pin Outer Diameter |
0.927 |
| Add-On |
927-042-CS |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Bore Diameter |
4.135 |
| Product Type |
Engine Piston |
| Piston Quantity |
1 |
| Second Compression Ring Thickness |
0.0640 |
| Industry |
Automotive |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.927 |
| Piston Volume |
-36.00 |
| Product Market |
Domestic |
| Piston Material |
2618 |
| Add-On |
J100F8-4135-5 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Domestic |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Title - Web |
JE Pistons Chevrolet Small Block Piston - 4.135 in. Bore - 1.425 in. CH, -36.00 CC |
| Add-On |
927-2950-15-51S |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Length |
2.950 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
