Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.060 in. Bore, 1.600 CD, Dome, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.060 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_INV |
SRP, Piston Set |
| Description_SHO |
Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Ford 302, 4.060 Bore, Dome, Set of 8 |
| Piston Head Type |
Dome |
| Engine Type |
ICE |
| Piston Pin Outside Diameter |
0.912 |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.188 |
| Piston Pin Wall Thickness |
0.140 |
| Piston Series |
SRP |
| Engine - Web |
Small Block |
| Wrist Pin Outer Diameter |
0.912 |
| Compression Height |
1.600 |
| Product Market |
Domestic |
| Product Type |
Engine Piston Kit |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.060 |
| Add-On |
S100S8-4060-5 |
| Add-On |
912-2750-14-51S |
| Industry |
Automotive |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Second Compression Ring Thickness |
0.0640 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Top Compression Ring Thickness |
0.0640 |
| Engine |
Small Block |
| Prop 65 Yes/No |
Yes |
| Title |
SRP - Ford, Small Block, 4.060 in. Bore, Piston Kit |
| Add-On |
927-042-CS |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Piston Volume |
18.00 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.060 in. Bore - 1.600 in. CH, 18.00 CC |
| Piston Pin Length |
2.750 |
| Piston Material |
2618 |
| Make |
FORD |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.140 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Wrist Pin Length |
2.750 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
