Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.020 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.020 in. Bore, 1.600 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 302, 4.020 Bore, Dome, Set of 8 |
| Description_SHO |
Piston Kit |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Length |
2.750 |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
No |
| Piston Volume |
18.00 |
| Bore Diameter |
4.020 |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
S100S8-4020-5 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Average Weight |
526 |
| Add-On |
927-042-CS |
| Product Market |
Domestic |
| Compression Height |
1.600 |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.912 |
| Title |
SRP - Ford, Small Block, 4.020 in. Bore, Piston Kit |
| Add-On |
912-2750-14-51S |
| Top Compression Ring Thickness |
0.0640 |
| Industry |
Automotive |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
Small Block |
| Piston Pin Wall Thickness |
0.140 |
| Engine Type |
ICE |
| Engine |
Small Block |
| Piston Material |
2618 |
| Ringset Included |
No |
| Piston Pin Length |
2.750 |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.020 in. Bore - 1.600 in. CH, 18.00 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Wrist Pin Wall Thickness |
0.140 |
| Make |
FORD |
| Piston Head Type |
Dome |
| Oil Ring Thickness |
0.188 |
| Piston Series |
SRP |
| Wrist Pin Outer Diameter |
0.912 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
