Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 4.020 Bore, 1.550 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.020 in. Bore, 1.550 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Chevrolet 350, 4.020 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Add-On |
S100S8-4020-5 |
| Add-On |
927-2500-15-51S |
| Cylinder Head |
STD CHEVROLET 23 DEG |
| Add-On |
927-042-CS |
| Piston Material |
2618 |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0640 |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
No |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Make - Web |
Chevrolet |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Oil Ring Thickness |
0.188 |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.020 in. Bore - 1.550 in. CH, -4.00 CC |
| Engine |
Small Block |
| Piston Pin Length |
2.500 |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0640 |
| Make |
CHEVROLET |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Piston Series |
SRP |
| Compression Height |
1.550 |
| Bore Diameter |
4.020 |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Product Type |
Engine Piston Kit |
| Piston Pin Outside Diameter |
0.927 |
| Piston Head Type |
Flat |
| Title |
SRP - Chevrolet, Small Block, 4.020 in. Bore, Piston Kit |
| Piston Volume |
-4.00 |
| Piston Average Weight |
438 |
| Engine - Web |
Small Block |
| Ring Set Included |
No |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Length |
2.500 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
