As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
BMW 535i Base United States N55B30 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.327 Bore, 1.275 CD, 0.866 Pin, Set of 6. |
| Description_EXT |
JE, BMW, N55B30, 3.327 in. Bore, 9.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
BMW N55B30, 84.50 Bore, Dish, Set of 6 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
European |
| Bore Diameter |
84.50 |
| Add-On |
JG1001-3327-AL |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.866 |
| Product Type |
Engine Piston Kit |
| Add-On |
866-2250-15-51C |
| Add-On |
866-063-MW |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Title |
JE Pistons - BMW, N55B30, 84.50 mm Bore, Piston Kit |
| Cylinder Head |
N55B30 |
| Piston Volume |
-14.70 |
| Title - Web |
JE Pistons BMW N55B30 Piston Kit - 84.50 mm Bore - 1.275 in. CH, -14.70 CC |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Piston Head Type |
Dish |
| Engine |
N55B30 |
| Piston Quantity |
6 |
| Compression Height |
1.275 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Material |
2618 |
| Piston Pin Length |
2.250 |
| Make - Web |
BMW |
| Engine - Web |
N55B30 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Make |
BMW |
| Ringset Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Outer Diameter |
0.866 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
