As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Audi 2.5L TFSI 20V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.248 Bore, 1.165 CD, 0.866 Pin, Set of 5. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Audi, TT RS 5 CYL, 3.248 in. Bore, 9.50:1, Inverted Dome/Dish, 5 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Audi 2.5L TFSI 20V, 82.50 Bore, Dish, Set of 5 |
| Ringset Included |
Yes |
| Piston Pin Material |
5115 |
| Engine |
TT RS 5 CYL |
| Product Market |
European |
| Piston Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.866 |
| Title |
JE Pistons - Audi, TT RS 5 Cyl, 82.50 mm Bore, Piston Kit |
| Piston Head Type |
Dish |
| Piston Volume |
-7.50 |
| Product Type |
Engine Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Piston Quantity |
5 |
| Engine Type |
ICE |
| Top Compression Ring Thickness |
0.0400 |
| Compression Height |
1.165 |
| Oil Ring Thickness |
0.111 |
| Piston Series |
JE Pistons |
| Make |
AUDI |
| Forging Type |
Round |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Outer Diameter |
0.866 |
| Engine - Web |
TT RS 5 Cyl |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 Yes/No |
Yes |
| Add-On |
866-063-MW |
| Bore Diameter |
82.50 |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Audi TT RS 5 Cyl Piston Kit - 82.50 mm Bore - 1.165 in. CH, -7.50 CC |
| Second Compression Ring Thickness |
0.0480 |
| Cylinder Head |
R5 TFSI 20V |
| Add-On |
866-2250-15-51C |
| Piston Material |
2618 |
| Add-On |
JG1001-3250 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Make - Web |
Audi |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
