Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Big Block 460 M-6049-SCJ |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.440 Bore, 1.250 CD, 0.990 Pin, Set of 8. |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Big Block Ford, 4.440 in. Bore, 1.250 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 460, 4.440 Bore, Flat, Set of 8 |
| Make |
FORD |
| Oil Ring Thickness |
0.218 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.150 |
| Forging Type |
FSR |
| Wrist Pin Outer Diameter |
0.990 |
| Product Market |
Domestic |
| Top Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Piston Pin Outside Diameter |
0.990 |
| Title |
SRP - Ford, Big Block, 4.440 in. Bore, Piston Kit |
| Bore Diameter |
4.440 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Piston Average Weight |
564 |
| Compression Height |
1.250 |
| Engine - Web |
Big Block |
| Wrist Pin Length |
2.930 |
| Ring Set Included |
No |
| Piston Material |
4032 |
| Add-On |
990-042-CS |
| Add-On |
990-2930-15-51S |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
No |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-3.00 |
| Industry |
Automotive |
| Cylinder Head |
SUPER COBRA JET |
| Engine |
Big Block |
| Piston Series |
SRP |
| Add-On |
J100F8-4440-5 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Length |
2.930 |
| Title - Web |
SRP Ford Big Block Piston Kit - 4.440 in. Bore - 1.250 in. CH, -3.00 CC |
| Make - Web |
Ford |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
