Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Oldsmobile 455 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.165 Bore, 1.750 CD, 0.980 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Oldsmobile, Big Block Oldsmobile, 4.165 in. Bore, 1.750 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Oldsmobile 455, 4.165 Bore, Dish, Set of 8 |
| Make |
OLDSMOBILE |
| Ringset Included |
No |
| Piston Head Type |
Dish |
| Oil Ring Thickness |
0.188 |
| Title |
SRP - Oldsmobile, Big Block, 4.165 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Top Compression Ring Thickness |
0.0640 |
| Piston Pin Length |
2.750 |
| Industry |
Automotive |
| Forging Type |
FSR |
| Piston Series |
SRP |
| Engine |
Big Block |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.750 |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Outside Diameter |
0.980 |
| Piston Volume |
-18.80 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Engine - Web |
Big Block |
| Wrist Pin Length |
2.750 |
| Wrist Pin Outer Diameter |
0.980 |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
4032 |
| Piston Average Weight |
587 |
| Add-On |
980-2750-15-51S |
| Add-On |
990-042-CS |
| Add-On |
S100S8-4165-5 |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0640 |
| Cylinder Head |
OLDSMOBILE 455 |
| Title - Web |
SRP Oldsmobile Big Block Piston Kit - 4.165 in. Bore - 1.750 in. CH, -18.80 CC |
| Bore Diameter |
4.165 |
| Out of Stock Message |
Call for Availability |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Oldsmobile |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
