Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Oldsmobile 455 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.165 Bore, 1.750 CD, 0.980 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Oldsmobile, Big Block Oldsmobile, 4.165 in. Bore, 1.750 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Oldsmobile 455, 4.165 Bore, Flat, Set of 8 |
| Wrist Pin Length |
2.750 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Product Type |
Engine Piston Kit |
| Engine - Web |
Big Block |
| Prop 65 Yes/No |
Yes |
| Piston Pin Outside Diameter |
0.980 |
| Piston Average Weight |
569 |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0640 |
| Piston Volume |
-5.00 |
| Ring Set Included |
No |
| Title |
SRP - Oldsmobile, Big Block, 4.165 in. Bore, Piston Kit |
| Product Market |
Domestic |
| Piston Material |
4032 |
| Bore Diameter |
4.165 |
| Industry |
Automotive |
| Add-On |
990-042-CS |
| Forging Type |
FSR |
| Cylinder Head |
OLDSMOBILE 455 |
| Title - Web |
SRP Oldsmobile Big Block Piston Kit - 4.165 in. Bore - 1.750 in. CH, -5.00 CC |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Top Compression Ring Thickness |
0.0640 |
| Add-On |
980-2750-15-51S |
| Engine |
Big Block |
| Add-On |
S100S8-4165-5 |
| Compression Height |
1.750 |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Make |
OLDSMOBILE |
| Oil Ring Thickness |
0.188 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Length |
2.750 |
| Piston Series |
SRP |
| Make - Web |
Oldsmobile |
| Wrist Pin Outer Diameter |
0.980 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
