As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Big Block 502 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.530 Bore, 1.215 CD, 0.990 Pin, Set of 8. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Chevrolet, Big Block Chevrolet, 4.530 in. Bore, 1.215 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Chevrolet 502, 4.530 Bore, Dome, Set of 8 |
| Description_SHO |
Piston Kit |
| Product Type |
Engine Piston Kit |
| Piston Volume |
49.00 |
| Piston Pin Wall Thickness |
0.180 |
| Engine - Web |
Big Block |
| Industry |
Automotive |
| Product Market |
Domestic |
| Compression Height |
1.215 |
| Top Compression Ring Thickness |
0.0440 |
| Title |
JE Pistons - Chevrolet, Big Block, 4.530 in. Bore, Piston Kit |
| Piston Quantity |
8 |
| Piston Average Weight |
665 |
| Piston Material |
2618 |
| Bore Diameter |
4.530 |
| Add-On |
990-2500-18-51C |
| Add-On |
JG7708-4530-5 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Cylinder Head |
OPEN CHAMBER |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
990-073-MW |
| Wrist Pin Outer Diameter |
0.990 |
| Ring Set Included |
No |
| Piston Pin Length |
2.500 |
| Second Compression Ring Thickness |
0.0440 |
| Piston Pin Outside Diameter |
0.990 |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Chevrolet Big Block Piston Kit - 4.530 in. Bore - 1.215 in. CH, 49.00 CC |
| Make |
CHEVROLET |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Length |
2.500 |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.149 |
| Forging Type |
FSR |
| Engine |
Big Block |
| Piston Head Type |
Dome |
| Piston Series |
JE Pistons |
| Ringset Included |
No |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
