Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 289/302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.020 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.020 in. Bore, 1.600 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 289/302, 4.020 Bore, Dish, Set of 8 |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.020 in. Bore - 1.600 in. CH, -14.50 CC |
| Out of Stock Message |
Call for Availability |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Volume |
-14.50 |
| Piston Material |
4032 |
| Second Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Make - Web |
Ford |
| Add-On |
S100S8-4020-5 |
| Piston Pin Length |
2.750 |
| Industry |
Automotive |
| Engine |
Small Block |
| Engine Type |
ICE |
| Add-On |
912-2750-14-51S |
| Prop 65 Yes/No |
Yes |
| Piston Pin Wall Thickness |
0.140 |
| Add-On |
927-042-CS |
| Piston Head Type |
Dish |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.750 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine - Web |
Small Block |
| Piston Average Weight |
488 |
| Top Compression Ring Thickness |
0.0640 |
| Compression Height |
1.600 |
| Oil Ring Thickness |
0.188 |
| Piston Series |
SRP |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.020 |
| Piston Pin Outside Diameter |
0.912 |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Ringset Included |
No |
| Title |
SRP - Ford, Small Block, 4.020 in. Bore, Piston Kit |
| Make |
FORD |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Outer Diameter |
0.912 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
