Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 289/302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.010 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.010 in. Bore, 1.600 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Ford 289/302, 4.010 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Oil Ring Thickness |
0.188 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Second Compression Ring Thickness |
0.0640 |
| Forging Type |
FSR |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
SRP |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Make - Web |
Ford |
| Prop 65 Yes/No |
Yes |
| Piston Head Type |
Dish |
| Engine Type |
ICE |
| Top Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Ringset Included |
No |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.010 |
| Piston Pin Outside Diameter |
0.912 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.010 in. Bore - 1.600 in. CH, -14.50 CC |
| Out of Stock Message |
Call for Availability |
| Product Market |
Domestic |
| Ring Set Included |
No |
| Wrist Pin Outer Diameter |
0.912 |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Length |
2.750 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Make |
FORD |
| Title |
SRP - Ford, Small Block, 4.010 in. Bore, Piston Kit |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Wall Thickness |
0.140 |
| Piston Average Weight |
480 |
| Piston Material |
4032 |
| Compression Height |
1.600 |
| Piston Volume |
-14.50 |
| Add-On |
J100F8-4010-5 |
| Add-On |
912-2750-14-51S |
| Add-On |
927-042-CS |
| Engine - Web |
Small Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
