Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 289/302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.000 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.000 in. Bore, 1.600 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 289/302, 4.000 Bore, Dish, Set of 8 |
| Compression Height |
1.600 |
| Title |
SRP - Ford, Small Block, 4.000 in. Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.912 |
| Wrist Pin Outer Diameter |
0.912 |
| Piston Material |
4032 |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.188 |
| Product Market |
Domestic |
| Piston Pin Wall Thickness |
0.140 |
| Engine - Web |
Small Block |
| Bore Diameter |
4.000 |
| Top Compression Ring Thickness |
0.0640 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Wrist Pin Wall Thickness |
0.140 |
| Piston Head Type |
Dish |
| Piston Average Weight |
474 |
| Piston Series |
SRP |
| Add-On |
912-2750-14-51S |
| Piston Volume |
-14.50 |
| Second Compression Ring Thickness |
0.0640 |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Length |
2.750 |
| Make |
FORD |
| Add-On |
927-042-CS |
| Add-On |
S100S8-4000-5 |
| Ringset Included |
No |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.000 in. Bore - 1.600 in. CH, -14.50 CC |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Engine |
Small Block |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Make - Web |
Ford |
| Wrist Pin Length |
2.750 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
