Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351W Windsor Stroker |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.000 Bore, 1.230 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.000 in. Bore, 1.230 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 351 Windsor, 4.000 Bore, Flat, Set of 8 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Top Compression Ring Thickness |
0.0640 |
| Product Market |
Domestic |
| Wrist Pin Length |
2.750 |
| Title |
SRP - Ford, Small Block, 4.000 in. Bore, Piston Kit |
| Piston Material |
4032 |
| Piston Volume |
-5.00 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Ring Set Included |
No |
| Piston Pin Outside Diameter |
0.927 |
| Product Type |
Engine Piston Kit |
| Piston Average Weight |
430 |
| Bore Diameter |
4.000 |
| Compression Height |
1.230 |
| Engine - Web |
Small Block |
| Prop 65 Yes/No |
Yes |
| Engine |
Small Block |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.750 |
| Ringset Included |
No |
| Piston Head Type |
Flat |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Add-On |
927-042-CS |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0640 |
| Piston Pin Wall Thickness |
0.150 |
| Add-On |
S100S8-4000-5 |
| Oil Ring Thickness |
0.188 |
| Piston Series |
SRP |
| Make |
FORD |
| Add-On |
927-2750-15-51S |
| Industry |
Automotive |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.000 in. Bore - 1.230 in. CH, -5.00 CC |
| Forging Type |
FSR |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
