Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.135 Bore, 1.125 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.135 in. Bore, 1.125 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Chevrolet 400, 4.135 Bore, Dome, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Product Market |
Domestic |
| Piston Series |
SRP |
| Top Compression Ring Thickness |
0.0640 |
| Wrist Pin Wall Thickness |
0.150 |
| Make |
CHEVROLET |
| Piston Pin Outside Diameter |
0.927 |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Piston Material |
2618 |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.218 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Outer Diameter |
0.927 |
| Bore Diameter |
4.135 |
| Title |
SRP - Chevrolet, Small Block, 4.135 in. Bore, Piston Kit |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Volume |
4.00 |
| Compression Height |
1.125 |
| Piston Average Weight |
432 |
| Forging Type |
FSR |
| Make - Web |
Chevrolet |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine - Web |
Small Block |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.750 |
| Add-On |
927-042-CS |
| Prop 65 Yes/No |
Yes |
| Engine |
Small Block |
| Piston Head Type |
Dome |
| Industry |
Automotive |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.135 in. Bore - 1.125 in. CH, 4.00 CC |
| Ringset Included |
No |
| Add-On |
927-2750-15-51S |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
J100F8-4135-5 |
| Piston Pin Length |
2.750 |
| Out of Stock Message |
Call for Availability |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
