Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.135 Bore, 1.425 CD, 0.927 Pin, Set of 8. |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.135 in. Bore, 1.425 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 400, 4.135 Bore, Flat, Set of 8 |
| Piston Series |
SRP |
| Oil Ring Thickness |
0.188 |
| Product Market |
Domestic |
| Ringset Included |
No |
| Top Compression Ring Thickness |
0.0640 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Average Weight |
492 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Bore Diameter |
4.135 |
| Forging Type |
FSR |
| Piston Pin Outside Diameter |
0.927 |
| Piston Pin Wall Thickness |
0.150 |
| Title |
SRP - Chevrolet, Small Block, 4.135 in. Bore, Piston Kit |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.750 |
| Industry |
Automotive |
| Compression Height |
1.425 |
| Product Type |
Engine Piston Kit |
| Make |
CHEVROLET |
| Add-On |
J100F8-4135-5 |
| Add-On |
927-2750-15-51S |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Piston Pin Material |
5115 |
| Piston Volume |
-5.00 |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0640 |
| Piston Head Type |
Flat |
| Add-On |
927-042-CS |
| Piston Material |
4032 |
| Engine Type |
ICE |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.135 in. Bore - 1.425 in. CH, -5.00 CC |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
