SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 4032, Inv Dome/Dish, 4.010 Bore, 1.230 CD, 0.927 Pin, Set of 1. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_EXT |
SRP Pro 4032, Ford, Small Block Ford, 4.010 in. Bore, 1.230 CD, Inverted Dome/Dish, Single Piston |
| Description_INV |
SRP Pro, Piston |
| Description_SHO |
Piston |
| Description_TLE |
Ford 302, 4.010 Bore, Dish, Set of 1 |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Ringset Included |
Yes |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine |
Small Block |
| Forging Type |
FSR |
| Piston Series |
SRP Pro 4032 |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Piston Pin Outside Diameter |
0.927 |
| Piston Volume |
-19.00 |
| Piston Head Type |
Dish |
| Compression Height |
1.230 |
| Make |
FORD |
| Prop 65 (C, R or CR) |
CR |
| Oil Ring Thickness |
0.119 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine - Web |
Small Block |
| Make - Web |
Ford |
| Ring Set Included |
Yes |
| Prop 65 Yes/No |
Yes |
| Product Market |
Domestic |
| Piston Average Weight |
390 |
| Product Type |
Engine Piston |
| Second Compression Ring Thickness |
0.0600 |
| Add-On |
JG3101-4010-4 |
| Title - Web |
SRP Pro 4032 Ford Small Block Piston - 4.010 in. Bore - 1.230 in. CH, -19.00 CC |
| Out of Stock Message |
Call for Availability |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Title |
SRP Pro 4032 - Ford, Small Block, 4.010 in. Bore, Piston |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Single Replacement Pistons |
| Bore Diameter |
4.010 |
| Industry |
Automotive |
| Add-On |
927-2250-15-51C |
| Add-On |
927-073-MW |
| Piston Material |
4032 |
| Top Compression Ring Thickness |
0.0480 |
| Wrist Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
