SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DES |
Piston Set, 4032, Flat Top, 4.060 Bore, 1.100 CD, 0.927 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Ford, Small Block Ford, 4.060 in. Bore, 1.100 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_TLE |
Ford 302, 4.060 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Piston Volume |
-5.00 |
| Title - Web |
SRP Pro 4032 Ford Small Block Piston Kit - 4.060 in. Bore - 1.100 in. CH, -5.00 CC |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Piston Material |
4032 |
| Forging Type |
FSR |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Second Compression Ring Thickness |
0.0600 |
| Piston Pin Length |
2.250 |
| Compression Height |
1.100 |
| Add-On |
JG31F1-4060-0 |
| Out of Stock Message |
Call for Availability |
| Add-On |
927-2250-15-51C |
| Engine |
Small Block |
| Add-On |
927-073-MW |
| Ringset Included |
Yes |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Title |
SRP Pro 4032 - Ford, Small Block, 4.060 in. Bore, Piston Kit |
| Piston Series |
SRP Pro 4032 |
| Product Market |
Domestic |
| Oil Ring Thickness |
0.149 |
| Top Compression Ring Thickness |
0.0480 |
| Piston Pin Outside Diameter |
0.927 |
| Make |
FORD |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Engine Type |
ICE |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Piston Pin Wall Thickness |
0.150 |
| Piston Average Weight |
404 |
| Bore Diameter |
4.060 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Length |
2.250 |
| Engine - Web |
Small Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
