SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.060 Bore, 1.165 CD, 0.927 Pin, Set of 8. |
| Description_EXT |
SRP Pro 4032, Ford, Small Block Ford, 4.060 in. Bore, 1.165 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP Pro, Piston Set |
| Description_SHO |
Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 302, 4.060 Bore, Flat, Set of 8 |
| Piston Volume |
-5.00 |
| Piston Pin Outside Diameter |
0.927 |
| Forging Type |
FSR |
| Piston Head Type |
Flat |
| Oil Ring Thickness |
0.119 |
| Piston Average Weight |
414 |
| Title |
SRP Pro 4032 - Ford, Small Block, 4.060 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Piston Series |
SRP Pro 4032 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Bore Diameter |
4.060 |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0600 |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG31F1-4060-0 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Compression Height |
1.165 |
| Add-On |
927-073-MW |
| Piston Pin Length |
2.250 |
| Industry |
Automotive |
| Add-On |
927-2250-15-51C |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Product Market |
Domestic |
| Ringset Included |
Yes |
| Top Compression Ring Thickness |
0.0480 |
| Make |
FORD |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
Small Block |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Title - Web |
SRP Pro 4032 Ford Small Block Piston Kit - 4.060 in. Bore - 1.165 in. CH, -5.00 CC |
| Piston Material |
4032 |
| Engine |
Small Block |
| Make - Web |
Ford |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
