SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.005 Bore, 1.165 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Ford, Small Block Ford, 4.005 in. Bore, 1.165 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 302, 4.005 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine |
Small Block |
| Oil Ring Thickness |
0.119 |
| Piston Pin Length |
2.250 |
| Make - Web |
Ford |
| Piston Pin Wall Thickness |
0.150 |
| Forging Type |
FSR |
| Ringset Included |
Yes |
| Engine Type |
ICE |
| Title - Web |
SRP Pro 4032 Ford Small Block Piston Kit - 4.005 in. Bore - 1.165 in. CH, -5.00 CC |
| Piston Series |
SRP Pro 4032 |
| Piston Pin Outside Diameter |
0.927 |
| Industry |
Automotive |
| Piston Pin Material |
5115 |
| Piston Volume |
-5.00 |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Flat |
| Make |
FORD |
| Title |
SRP Pro 4032 - Ford, Small Block, 4.005 in. Bore, Piston Kit |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Wall Thickness |
0.150 |
| Add-On |
JG3101-4000-7 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Piston Average Weight |
402 |
| Bore Diameter |
4.005 |
| Compression Height |
1.165 |
| Product Market |
Domestic |
| Add-On |
927-2250-15-51C |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Piston Material |
4032 |
| Second Compression Ring Thickness |
0.0600 |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0480 |
| Add-On |
927-073-MW |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
