SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.020 Bore, 1.125 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Chevrolet, Small Block Chevrolet, 4.020 in. Bore, 1.125 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_TLE |
Chevrolet 350, 4.020 Bore, Dish, Set of 8 |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Wrist Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.149 |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0480 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.020 in. Bore, Piston Kit |
| Wrist Pin Outer Diameter |
0.927 |
| Piston Pin Outside Diameter |
0.927 |
| Compression Height |
1.125 |
| Make |
CHEVROLET |
| Piston Material |
4032 |
| Wrist Pin Length |
2.250 |
| Engine - Web |
Small Block |
| Bore Diameter |
4.020 |
| Product Market |
Domestic |
| Add-On |
927-073-MW |
| Piston Pin Material |
5115 |
| Product Type |
Engine Piston Kit |
| Add-On |
JG3101-4020-2 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Piston Volume |
-16.00 |
| Add-On |
927-2250-15-51C |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Piston Average Weight |
374 |
| Ring Set Included |
Yes |
| Engine |
Small Block |
| Piston Pin Length |
2.250 |
| Ringset Included |
Yes |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Piston Series |
SRP Pro 4032 |
| Out of Stock Message |
Call for Availability |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.020 in. Bore - 1.125 in. CH, -16.00 CC |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0600 |
| Piston Head Type |
Dish |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
