SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.000 Bore, 1.000 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Chevrolet, Small Block Chevrolet, 4.000 in. Bore, 1.000 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 350, 4.000 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Ringset Included |
Yes |
| Forging Type |
FSR |
| Piston Pin Length |
2.250 |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.150 |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.000 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Piston Series |
SRP Pro 4032 |
| Piston Pin Material |
5115 |
| Engine |
Small Block |
| Oil Ring Thickness |
0.149 |
| Wrist Pin Outer Diameter |
0.927 |
| Make |
CHEVROLET |
| Second Compression Ring Thickness |
0.0600 |
| Piston Pin Outside Diameter |
0.927 |
| Compression Height |
1.000 |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Dish |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-16.00 |
| Ring Set Included |
Yes |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Industry |
Automotive |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Product Market |
Domestic |
| Add-On |
927-2250-15-51C |
| Piston Average Weight |
332 |
| Add-On |
927-073-MW |
| Product Type |
Engine Piston Kit |
| Piston Material |
4032 |
| Bore Diameter |
4.000 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.000 in. Bore - 1.000 in. CH, -16.00 CC |
| Add-On |
JG3101-4000-7 |
| Out of Stock Message |
Call for Availability |
| Top Compression Ring Thickness |
0.0480 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
