SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Dome, 4.005 Bore, 1.125 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Chevrolet, Small Block Chevrolet, 4.005 in. Bore, 1.125 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 350, 4.005 Bore, Dome, Set of 8 |
| Piston Pin Material |
5115 |
| Piston Series |
SRP Pro 4032 |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.005 in. Bore - 1.125 in. CH, 7.00 CC |
| Engine |
Small Block |
| Piston Head Type |
Dome |
| Piston Pin Length |
2.250 |
| Second Compression Ring Thickness |
0.0600 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.149 |
| Ringset Included |
Yes |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Wall Thickness |
0.150 |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Add-On |
927-2250-15-51C |
| Piston Average Weight |
412 |
| Piston Material |
4032 |
| Industry |
Automotive |
| Make |
CHEVROLET |
| Piston Pin Outside Diameter |
0.927 |
| Piston Volume |
7.00 |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Compression Height |
1.125 |
| Out of Stock Message |
Call for Availability |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.005 in. Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0480 |
| Add-On |
JG3101-4000-7 |
| Product Market |
Domestic |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
927-073-MW |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Bore Diameter |
4.005 |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
Yes |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
