SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford 4.6L Modular 2V |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 4032, Flat Top, 3.552 Bore, 1.220 CD, 0.866 Pin, Set of 1. |
| Description_INV |
SRP Pro, Piston |
| Description_EXT |
SRP Pro 4032, Ford, Modular Ford, 3.552 in. Bore, 1.220 CD, Flat Top, Right Piston |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston |
| Description_TLE |
Ford 4.6L Modular, 3.552 Bore, Flat, Set of 1 |
| Piston Pin Length |
2.250 |
| Bore Diameter |
3.552 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Single Replacement Pistons |
| Wrist Pin Length |
2.250 |
| Industry |
Automotive |
| Top Compression Ring Thickness |
0.0480 |
| Product Type |
Engine Piston |
| Cylinder Head |
MODULAR 4.6 2V |
| Piston Average Weight |
336 |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Add-On |
JG3208-3551-0 |
| Second Compression Ring Thickness |
0.0600 |
| Piston Material |
4032 |
| Prop 65 Yes/No |
Yes |
| Add-On |
866-063-MW |
| Add-On |
866-2250-15-51C |
| Out of Stock Message |
Call for Availability |
| Piston Volume |
-3.00 |
| Title - Web |
SRP Pro 4032 Ford Modular Piston - 3.552 in. Bore - 1.220 in. CH, -3.00 CC |
| Make - Web |
Ford |
| Oil Ring Thickness |
0.119 |
| Make |
FORD |
| Forging Type |
FSR |
| Piston Pin Outside Diameter |
0.866 |
| Engine |
Modular |
| Piston Series |
SRP Pro 4032 |
| Piston Pin Material |
5115 |
| Title |
SRP Pro 4032 - Ford, Modular, 3.552 in. Bore, Piston |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Piston Orientation |
Right |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.220 |
| Piston Head Type |
Flat |
| Product Market |
Domestic |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.866 |
| Engine - Web |
Modular |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
