SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet LS2 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.075 Bore, 1.340 CD, 0.945 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Chevrolet, LS Gen III/IV, 4.075 in. Bore, 1.340 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_TLE |
Chevrolet LS2, 4.075 Bore, Flat, Set of 8 |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Make - Web |
Chevrolet |
| Second Compression Ring Thickness |
0.0600 |
| Title - Web |
SRP Pro 4032 Chevrolet LS Gen III/IV Piston Kit - 4.075 in. Bore - 1.330 in. CH, -5.00 CC |
| Engine |
LS Gen III/IV |
| Add-On |
JG31F1-4075-5 |
| Add-On |
945-073-MW |
| Add-On |
945-2250-15-51C |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ringset Included |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Flat |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Volume |
-5.00 |
| Cylinder Head |
LSX/L92 12 DEG |
| Industry |
Automotive |
| Piston Pin Material |
5115 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.250 |
| Engine - Web |
LS Gen III/IV |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Engine Type |
ICE |
| Top Compression Ring Thickness |
0.0480 |
| Piston Average Weight |
443 |
| Piston Pin Wall Thickness |
0.150 |
| Product Market |
Domestic |
| Compression Height |
1.330 |
| Oil Ring Thickness |
0.119 |
| Bore Diameter |
4.075 |
| Make |
CHEVROLET |
| Piston Material |
4032 |
| Piston Pin Outside Diameter |
0.945 |
| Piston Series |
SRP Pro 4032 |
| Forging Type |
FSR |
| Title |
SRP Pro 4032 - Chevrolet, LS Gen III/IV, 4.075 in. Bore, Piston Kit |
| Ring Set Included |
Yes |
| Wrist Pin Outer Diameter |
0.945 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
