SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.030 Bore, 1.560 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro, Chevrolet, Small Block Chevrolet, 4.030 in. Bore, 1.560 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
SRP Pro 4032 - Chevrolet, Small Block, 4.030 in. Bore, Piston Kit |
| Piston Average Weight |
480 |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.030 in. Bore, Piston Kit |
| Make |
CHEVROLET |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.119 |
| Product Market |
Domestic |
| Compression Height |
1.560 |
| Bore Diameter |
4.030 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Piston Series |
SRP Pro |
| Top Compression Ring Thickness |
0.0480 |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Length |
2.250 |
| Engine Type |
ICE |
| Piston Volume |
-10.00 |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.030 in. Bore - 1.560 in. CH, -10.00 CC |
| Piston Pin Outside Diameter |
0.927 |
| Product Type |
Engine Piston Kit |
| Cylinder Head |
STD CHEVROLET 23 DEG |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
Yes |
| Engine - Web |
Small Block |
| Piston Material |
4032 |
| Add-On |
927-2250-15-51C |
| Engine |
Small Block |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Dish |
| Piston Pin Length |
2.250 |
| Prop 65 Yes/No |
Yes |
| Add-On |
927-073-MW |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0600 |
| Add-On |
JG31F8-4030-2 |
| Industry |
Automotive |
| Ringset Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
