As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Toyota 1FZ-FE Stroker |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.957 Bore, 1.535 CD, 1.024 Pin, Set of 6. |
| Description_EXT |
JE, Toyota, 1FZ-FE, 3.957 in. Bore, 10.00:1, Dome, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Toyota 1FZ-FE, 100.50 Bore, Dome, Set of 6 |
| Industry |
Automotive |
| Piston Material |
2618 |
| Piston Volume |
-0.20 |
| Cylinder Head |
1FZ-FE |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
JE Pistons Toyota 1FZ-FE Piston Kit - 100.50 mm Bore - 1.535 in. CH, -0.20 CC |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.500 |
| Piston Series |
JE Pistons |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
024-2500-20-51S |
| Engine |
1FZ-FE |
| Add-On |
JG1001-3957 |
| Piston Pin Length |
2.500 |
| Prop 65 Yes/No |
Yes |
| Add-On |
031-042-CS |
| Make - Web |
Toyota |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Title |
JE Pistons - Toyota, 1FZ-FE, 100.50 mm Bore, Piston Kit |
| Forging Type |
Round |
| Piston Pin Outside Diameter |
1.024 |
| Piston Pin Wall Thickness |
0.200 |
| Engine Type |
ICE |
| Make |
TOYOTA |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Quantity |
6 |
| Product Market |
Sport Compact |
| Piston Pin Material |
5115 |
| Compression Height |
1.535 |
| Piston Average Weight |
471 |
| Top Compression Ring Thickness |
0.0400 |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Bore Diameter |
100.50 |
| Piston Head Type |
Dome |
| Wrist Pin Outer Diameter |
1.024 |
| Wrist Pin Wall Thickness |
0.200 |
| Engine - Web |
1FZ-FE |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
5.0000 |
