As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ37VHR |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.760 Bore, 1.198 CD, 0.866 Pin, Set of 6. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Nissan, VQ37VHR, 3.760 in. Bore, 10.00:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Nissan VQ37VHR, 95.50 Bore, Dish, Set of 6 |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
JE Pistons Nissan VQ37VHR Piston Kit - 95.50 mm Bore - 1.198 in. CH, -8.80 CC |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3760 |
| Piston Material |
2618 |
| Add-On |
866-063-MW |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Second Compression Ring Thickness |
0.0480 |
| Piston Volume |
-8.80 |
| Add-On |
866-2250-15-51C |
| Industry |
Automotive |
| Cylinder Head |
VQ37VHR |
| Piston Quantity |
6 |
| Prop 65 Yes/No |
Yes |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Length |
2.250 |
| Product Type |
Engine Piston Kit |
| Piston Head Type |
Dish |
| Engine - Web |
VQ37VHR |
| Make - Web |
Nissan |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Title |
JE Pistons - Nissan, VQ37VHR, 95.50 mm Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.866 |
| Piston Average Weight |
415 |
| Ringset Included |
Yes |
| Make |
NISSAN |
| Oil Ring Thickness |
0.111 |
| Piston Pin Material |
5115 |
| Engine |
VQ37VHR |
| Top Compression Ring Thickness |
0.0400 |
| Forging Type |
FSR |
| Product Market |
Sport Compact |
| Bore Diameter |
95.50 |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Compression Height |
1.198 |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
