As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ37VHR |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.780 Bore, 1.198 CD, 0.866 Pin, Set of 1. |
| Description_INV |
JE Pistons, Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Nissan, VQ37VHR, 3.779 in. Bore, 8.50:1, Inverted Dome/Dish, Right Piston |
| Description_TLE |
Nissan VQ37VHR, 96.00 Bore, Dish, Set of 1 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston |
| Bore Diameter |
96.00 |
| Add-On |
866-2250-15-51C |
| Add-On |
866-063-MW |
| Add-On |
JG1001-3780 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Compression Height |
1.198 |
| Forging Type |
FSR |
| Engine |
VQ37VHR |
| Make |
NISSAN |
| Industry |
Automotive |
| Engine Type |
ICE |
| Cylinder Head |
VQ37VHR |
| Make - Web |
Nissan |
| Engine - Web |
VQ37VHR |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Outside Diameter |
0.866 |
| Piston Quantity |
1 |
| Piston Series |
JE Pistons |
| Product Type |
Engine Piston |
| Second Compression Ring Thickness |
0.0480 |
| Piston Material |
2618 |
| Ringset Included |
Yes |
| Product Market |
Sport Compact |
| Piston Head Type |
Dish |
| Piston Pin Wall Thickness |
0.150 |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
383 |
| Piston Pin Length |
2.250 |
| Piston Orientation |
Right |
| Oil Ring Thickness |
0.111 |
| Piston Pin Material |
5115 |
| Piston Volume |
-23.30 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Title |
JE Pistons - Nissan, VQ37VHR, 96.00 mm Bore, Piston |
| Title - Web |
JE Pistons Nissan VQ37VHR Piston - 96.00 mm Bore - 1.198 in. CH, -23.30 CC |
| Top Compression Ring Thickness |
0.0400 |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.866 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
