As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35HR |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 3.780 Bore, 1.198 CD, 0.866 Pin, Set of 1. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Nissan, VQ35HR, 3.779 in. Bore, 11.50:1, Dome, Right Piston |
| Description_INV |
JE Pistons, Piston |
| Description_SHO |
Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Nissan VQ35HR, 96.00 Bore, Dome, Set of 1 |
| Add-On |
866-063-MW |
| Add-On |
866-2250-15-51C |
| Add-On |
JG1001-3780 |
| Bore Diameter |
96.00 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Compression Height |
1.198 |
| Cylinder Head |
VQ35HR |
| Engine Type |
ICE |
| Engine |
VQ35HR |
| Make |
NISSAN |
| Industry |
Automotive |
| Forging Type |
FSR |
| Make - Web |
Nissan |
| Engine - Web |
VQ35HR |
| Product Market |
Sport Compact |
| Ringset Included |
Yes |
| Piston Quantity |
1 |
| Piston Pin Material |
5115 |
| Prop 65 Yes/No |
Yes |
| Oil Ring Thickness |
0.111 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Material |
2618 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Orientation |
Right |
| Piston Average Weight |
411 |
| Piston Series |
JE Pistons |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.250 |
| Out of Stock Message |
Call for Availability |
| Product Type |
Engine Piston |
| Piston Head Type |
Dome |
| Second Compression Ring Thickness |
0.0480 |
| Piston Volume |
8.70 |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Title |
JE Pistons - Nissan, VQ35HR, 96.00 mm Bore, Piston |
| Top Compression Ring Thickness |
0.0400 |
| Title - Web |
JE Pistons Nissan VQ35HR Piston - 96.00 mm Bore - 1.198 in. CH, 8.70 CC |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
