As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35HR |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.780 Bore, 1.198 CD, 0.866 Pin, Set of 6. |
| Description_EXT |
JE, Nissan, VQ35HR, 3.779 in. Bore, 11.50:1, Dome, 6 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan VQ35HR, 96.00 Bore, Dome, Set of 6 |
| Piston Pin Outside Diameter |
0.866 |
| Wrist Pin Outer Diameter |
0.866 |
| Piston Head Type |
Dome |
| Piston Pin Material |
5115 |
| Piston Series |
JE Pistons |
| Ringset Included |
Yes |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Make |
NISSAN |
| Engine - Web |
VQ35HR |
| Piston Pin Length |
2.250 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
96.00 |
| Oil Ring Thickness |
0.111 |
| Industry |
Automotive |
| Title |
JE Pistons - Nissan, VQ35HR, 96.00 mm Bore, Piston Kit |
| Product Market |
Sport Compact |
| Product Type |
Engine Piston Kit |
| Engine |
VQ35HR |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Compression Height |
1.198 |
| Piston Quantity |
6 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Length |
2.250 |
| Add-On |
866-2250-15-51C |
| Cylinder Head |
VQ35HR |
| Piston Average Weight |
411 |
| Prop 65 Yes/No |
Yes |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3780 |
| Second Compression Ring Thickness |
0.0480 |
| Piston Volume |
8.70 |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
866-063-MW |
| Title - Web |
JE Pistons Nissan VQ35HR Piston Kit - 96.00 mm Bore - 1.198 in. CH, 8.70 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Nissan |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
