As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35HR |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.760 Bore, 1.198 CD, 0.866 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Nissan, VQ35HR, 3.760 in. Bore, 10.00:1, Dome, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan VQ35HR, 95.50 Bore, Dome, Set of 6 |
| Industry |
Automotive |
| Cylinder Head |
VQ35HR |
| Second Compression Ring Thickness |
0.0480 |
| Make - Web |
Nissan |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Add-On |
JG1001-3760 |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
866-2250-15-51C |
| Piston Head Type |
Dome |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Ringset Included |
Yes |
| Piston Series |
JE Pistons |
| Make |
NISSAN |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Nissan VQ35HR Piston Kit - 95.50 mm Bore - 1.198 in. CH, 0.10 CC |
| Product Market |
Sport Compact |
| Add-On |
866-063-MW |
| Engine |
VQ35HR |
| Piston Quantity |
6 |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.866 |
| Oil Ring Thickness |
0.111 |
| Engine Type |
ICE |
| Product Type |
Engine Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
95.50 |
| Compression Height |
1.198 |
| Forging Type |
FSR |
| Piston Average Weight |
395 |
| Title |
JE Pistons - Nissan, VQ35HR, 95.50 mm Bore, Piston Kit |
| Piston Material |
2618 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Pin Material |
5115 |
| Piston Volume |
0.10 |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Engine - Web |
VQ35HR |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
