As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35DE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.760 Bore, 1.165 CD, 0.866 Pin, Set of 6. |
| Description_EXT |
JE, Nissan, VQ35DE, 3.760 in. Bore, 8.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan VQ35DE, 95.50 Bore, Dish, Set of 6 |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.866 |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Product Type |
Engine Piston Kit |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
Sport Compact |
| Make |
NISSAN |
| Oil Ring Thickness |
0.111 |
| Bore Diameter |
95.50 |
| Prop 65 (C, R or CR) |
CR |
| Piston Quantity |
6 |
| Add-On |
866-2250-15-51C |
| Title |
JE Pistons - Nissan, VQ35DE, 95.50 mm Bore, Piston Kit |
| Piston Volume |
-12.60 |
| Industry |
Automotive |
| Piston Average Weight |
372 |
| Add-On |
866-063-MW |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Add-On |
JG1001-3760 |
| Piston Pin Outside Diameter |
0.866 |
| Compression Height |
1.165 |
| Piston Series |
JE Pistons |
| Ring Set Included |
Yes |
| Engine - Web |
VQ35DE |
| Wrist Pin Length |
2.250 |
| Engine |
VQ35DE |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Piston Pin Length |
2.250 |
| Ringset Included |
Yes |
| Title - Web |
JE Pistons Nissan VQ35DE Piston Kit - 95.50 mm Bore - 1.165 in. CH, -12.60 CC |
| Cylinder Head |
VQ35DE 3.5L |
| Out of Stock Message |
Call for Availability |
| Piston Material |
2618 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Nissan |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
