As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet LS1 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Chevrolet, LS Gen III/IV, 3.905 in. Bore, 1.315 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.905 Bore, 1.315 CD, 0.927 Pin, Set of 8. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet LS1, 3.905 Bore, Flat, Set of 8 |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
436 |
| Wrist Pin Length |
2.250 |
| Add-On |
927-073-MW |
| Add-On |
J68008-3900-3 |
| Product Type |
Engine Piston Kit |
| Add-On |
927-2250-15-51C |
| Ring Set Included |
No |
| Make |
CHEVROLET |
| Product Market |
Domestic |
| Wrist Pin Outer Diameter |
0.927 |
| Title |
JE Pistons - Chevrolet, LS Gen III/IV, 3.905 in. Bore, Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Piston Pin Outside Diameter |
0.927 |
| Bore Diameter |
3.905 |
| Compression Height |
1.315 |
| Prop 65 (C, R or CR) |
CR |
| Forging Type |
FSR |
| Second Compression Ring Thickness |
0.0600 |
| Piston Quantity |
8 |
| Piston Pin Wall Thickness |
0.150 |
| Industry |
Automotive |
| Piston Volume |
-2.00 |
| Piston Pin Length |
2.250 |
| Cylinder Head |
LSX/L92 12 DEG |
| Top Compression Ring Thickness |
0.0600 |
| Piston Material |
2618 |
| Engine |
LS Gen III/IV |
| Oil Ring Thickness |
0.1175 |
| Engine - Web |
LS Gen III/IV |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Ringset Included |
No |
| Title - Web |
JE Pistons Chevrolet LS Gen III/IV Piston Kit - 3.905 in. Bore - 1.315 in. CH, -2.00 CC |
| Make - Web |
Chevrolet |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
13.0000 |
