As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K20A |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.543 Bore, 1.176 CD, 0.866 Pin, Set of 1. |
| Description_DEF |
Engine Piston |
| Description_EXT |
JE, Acura, K Series, 3.543 in. Bore, 9.00:1, Inverted Dome/Dish, Single Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Honda K20A, 90.00 Bore, Dish, Set of 1 |
| Add-On |
JG1001-3543 |
| Add-On |
866-2250-15-51C |
| Add-On |
866-063-MW |
| Engine |
K Series |
| Compression Height |
1.176 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Cylinder Head |
K20 |
| Bore Diameter |
90.00 |
| Engine - Web |
K Series |
| Make |
ACURA |
| Industry |
Automotive |
| Oil Ring Thickness |
0.111 |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Out of Stock Message |
Call for Availability |
| Make - Web |
Acura |
| Product Market |
Sport Compact |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Piston Material |
2618 |
| Piston Pin Outside Diameter |
0.866 |
| Product Type |
Engine Piston |
| Piston Series |
JE Pistons |
| Ringset Included |
Yes |
| Piston Quantity |
1 |
| Piston Average Weight |
335 |
| Piston Head Type |
Dish |
| Prop 65 (C, R or CR) |
CR |
| Piston Volume |
-10.70 |
| Piston Pin Length |
2.250 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Top Compression Ring Thickness |
0.0400 |
| Title |
JE Pistons - Acura, K Series, 90.00 mm Bore, Piston |
| Title - Web |
JE Pistons Acura K Series Piston - 90.00 mm Bore - 1.176 in. CH, -10.70 CC |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
