As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda F22C |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.543 Bore, 1.181 CD, 0.905 Pin, Set of 1. |
| Description_DEF |
Engine Piston |
| Description_INV |
JE Pistons, Piston |
| Description_EXT |
JE, Honda, F Series, 3.543 in. Bore, 9.00:1, Inverted Dome/Dish, Single Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Honda F22C, 90.00 Bore, Dish, Set of 1 |
| Description_SHO |
Piston |
| Add-On |
905-073-MW |
| Add-On |
JG1001-3543 |
| Add-On |
905-2250-15-51C |
| Bore Diameter |
90.00 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Engine Type |
ICE |
| Engine |
F SERIES |
| Cylinder Head |
F20C1 |
| Compression Height |
1.181 |
| Engine - Web |
F Series |
| Piston Pin Outside Diameter |
0.905 |
| Forging Type |
FSR |
| Piston Pin Length |
2.250 |
| Product Type |
Engine Piston |
| Piston Pin Wall Thickness |
0.150 |
| Product Market |
Sport Compact |
| Make |
HONDA |
| Out of Stock Message |
Call for Availability |
| Piston Quantity |
1 |
| Oil Ring Thickness |
0.111 |
| Industry |
Automotive |
| Piston Head Type |
Dish |
| Piston Series |
JE Pistons |
| Piston Material |
2618 |
| Piston Average Weight |
333 |
| Piston Volume |
-20.00 |
| Piston Pin Material |
5115 |
| Make - Web |
Honda |
| Title |
JE Pistons - Honda, F Series, 90.00 mm Bore, Piston |
| Title - Web |
JE Pistons Honda F Series Piston - 90.00 mm Bore - 1.181 in. CH, -20.00 CC |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
Yes |
| Prop 65 Yes/No |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Second Compression Ring Thickness |
0.0480 |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
