As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda F20C |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.504 Bore, 1.181 CD, 0.905 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Honda, F Series, 3.504 in. Bore, 9.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Honda F20C, 89.00 Bore, Dish, Set of 4 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine |
F SERIES |
| Oil Ring Thickness |
0.111 |
| Piston Pin Length |
2.250 |
| Make - Web |
Honda |
| Wrist Pin Outer Diameter |
0.905 |
| Product Market |
Sport Compact |
| Out of Stock Message |
Call for Availability |
| Title |
JE Pistons - Honda, F Series, 89.00 mm Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
Yes |
| Piston Average Weight |
318 |
| Piston Head Type |
Dish |
| Engine Type |
ICE |
| Make |
HONDA |
| Forging Type |
FSR |
| Bore Diameter |
89.00 |
| Piston Series |
JE Pistons |
| Piston Pin Material |
5115 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.905 |
| Prop 65 Yes/No |
Yes |
| Add-On |
JG1001-3504 |
| Piston Material |
2618 |
| Piston Volume |
-13.20 |
| Industry |
Automotive |
| Top Compression Ring Thickness |
0.0400 |
| Cylinder Head |
F20C1 |
| Title - Web |
JE Pistons Honda F Series Piston Kit - 89.00 mm Bore - 1.181 in. CH, -13.20 CC |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Add-On |
905-2250-15-51C |
| Second Compression Ring Thickness |
0.0480 |
| Compression Height |
1.181 |
| Piston Quantity |
4 |
| Add-On |
905-073-MW |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Engine - Web |
F Series |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
