As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 3.5L Ecoboost V6 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 3.661 Bore, 1.240 CD, 0.905 Pin, Set of 1. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Ford, 3.5L EcoBoost Gen 1 V6, 3.661 in. Bore, 10.00:1, Dome, Left Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston |
| Description_TLE |
Ford 3.5L Eco Boost V6, 93.00 Bore, Dome, Set of 1 |
| Description_INV |
JE Pistons, Piston |
| Add-On |
905-073-MW |
| Add-On |
JG1001-3661 |
| Add-On |
905-2250-18-51C |
| Bore Diameter |
93.00 |
| Engine |
3.5L ECOBOOST GEN 1 V6 |
| Forging Type |
FSR |
| Cylinder Head |
ECOBOOST V6 |
| Piston Head Type |
Dome |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Out of Stock Message |
Call for Availability |
| Compression Height |
1.240 |
| Engine Type |
ICE |
| Make |
FORD |
| Piston Average Weight |
406 |
| Industry |
Automotive |
| Oil Ring Thickness |
0.111 |
| Make - Web |
Ford |
| Engine - Web |
3.5L EcoBoost Gen 1 V6 |
| Ringset Included |
Yes |
| Piston Pin Outside Diameter |
0.905 |
| Second Compression Ring Thickness |
0.0480 |
| Piston Series |
JE Pistons |
| Piston Volume |
-0.90 |
| Prop 65 Yes/No |
Yes |
| Title |
JE Pistons - Ford, 3.5L EcoBoost Gen 1 V6, 93.00 mm Bore, Piston |
| Product Type |
Engine Piston |
| Piston Pin Material |
5115 |
| Product Market |
Sport Compact |
| Piston Pin Length |
2.250 |
| Piston Material |
2618 |
| Title - Web |
JE Pistons Ford 3.5L EcoBoost Gen 1 V6 Piston - 93.00 mm Bore - 1.240 in. CH, -0.90 CC |
| Piston Orientation |
Left |
| Piston Quantity |
1 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Wall Thickness |
0.180 |
| Top Compression Ring Thickness |
0.0400 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Wall Thickness |
0.180 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
