As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 3.5L Ecoboost V6 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 3.652 Bore, 1.240 CD, 0.905 Pin, Set of 1. |
| Description_EXT |
JE, Ford, 3.5L EcoBoost Gen 1 V6, 3.651 in. Bore, 10.00:1, Dome, Right Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Ford 3.5L Eco Boost V6, 92.75 Bore, Dome, Set of 1 |
| Description_SHO |
Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Add-On |
JG1001-3652 |
| Add-On |
905-2250-18-51C |
| Add-On |
905-073-MW |
| Bore Diameter |
92.75 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Compression Height |
1.240 |
| Engine |
3.5L ECOBOOST GEN 1 V6 |
| Cylinder Head |
ECOBOOST V6 |
| Out of Stock Message |
Call for Availability |
| Engine Type |
ICE |
| Make |
FORD |
| Industry |
Automotive |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.111 |
| Make - Web |
Ford |
| Engine - Web |
3.5L EcoBoost Gen 1 V6 |
| Prop 65 Yes/No |
Yes |
| Piston Orientation |
Right |
| Piston Pin Length |
2.250 |
| Piston Volume |
-0.35 |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Dome |
| Piston Quantity |
1 |
| Ringset Included |
Yes |
| Title - Web |
JE Pistons Ford 3.5L EcoBoost Gen 1 V6 Piston - 92.75 mm Bore - 1.240 in. CH, -0.35 CC |
| Product Type |
Engine Piston |
| Piston Average Weight |
402 |
| Product Market |
Sport Compact |
| Piston Pin Material |
5115 |
| Piston Series |
JE Pistons |
| Second Compression Ring Thickness |
0.0480 |
| Title |
JE Pistons - Ford, 3.5L EcoBoost Gen 1 V6, 92.75 mm Bore, Piston |
| Piston Pin Wall Thickness |
0.180 |
| Piston Pin Outside Diameter |
0.905 |
| Piston Material |
2618 |
| Top Compression Ring Thickness |
0.0400 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.905 |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
