As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 4.6L Modular 4V Stroker |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.572 Bore, 1.200 CD, 0.866 Pin, Set of 8. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Ford, Modular Ford, 3.572 in. Bore, 1.200 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Ford 4.6L Modular, 3.572 Bore, Dish, Set of 8 |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Piston Average Weight |
338 |
| Product Type |
Engine Piston Kit |
| Bore Diameter |
3.572 |
| Wrist Pin Length |
2.250 |
| Engine - Web |
Modular |
| Piston Quantity |
8 |
| Piston Material |
2618 |
| Piston Volume |
-21.00 |
| Cylinder Head |
MODULAR 4.6 4V |
| Out of Stock Message |
Call for Availability |
| Top Compression Ring Thickness |
0.0480 |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Second Compression Ring Thickness |
0.0600 |
| Piston Pin Outside Diameter |
0.866 |
| Add-On |
866-063-MW |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Make |
FORD |
| Piston Head Type |
Dish |
| Industry |
Automotive |
| Title - Web |
JE Pistons Ford Modular Piston Kit - 3.572 in. Bore - 1.200 in. CH, -21.00 CC |
| Add-On |
866-2250-15-51C |
| Add-On |
JG3208-3571-0 |
| Make - Web |
Ford |
| Forging Type |
FSR |
| Title |
JE Pistons - Ford, Modular, 3.572 in. Bore, Piston Kit |
| Engine |
Modular |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.119 |
| Piston Pin Length |
2.250 |
| Compression Height |
1.200 |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
No |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
12.0000 |
