As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 4.6L Modular 4V |
| Description_DEF |
Engine Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_EXT |
JE, Ford, Modular Ford, 3.701 in. Bore, 1.220 CD, Dome, Right Piston |
| Description_DES |
Piston Single, 2618, Dome, 3.701 Bore, 1.220 CD, 0.866 Pin, Set of 1. |
| Description_INV |
JE Pistons, Piston |
| Description_TLE |
Ford 4.6L Modular, 3.701 Bore, Dome, Set of 1 |
| Description_SHO |
Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Add-On |
JG1008-3701 |
| Bore Diameter |
3.701 |
| Add-On |
866-063-MW |
| Add-On |
866-2250-15-51C |
| Engine |
Modular |
| Industry |
Automotive |
| Compression Height |
1.220 |
| Engine Type |
ICE |
| Cylinder Head |
MODULAR 4.6 4V |
| Forging Type |
FSR |
| Make |
FORD |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Domestic |
| Make - Web |
Ford |
| Engine - Web |
Modular |
| Piston Average Weight |
402 |
| Oil Ring Thickness |
0.111 |
| Piston Volume |
0.80 |
| Piston Pin Length |
2.250 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dome |
| Piston Pin Outside Diameter |
0.866 |
| Piston Material |
2618 |
| Product Market |
Domestic |
| Product Type |
Engine Piston |
| Piston Quantity |
1 |
| Piston Series |
JE Pistons |
| Out of Stock Message |
Call for Availability |
| Piston Orientation |
Right |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Top Compression Ring Thickness |
0.0400 |
| Ringset Included |
No |
| Title - Web |
JE Pistons Ford Modular Piston - 3.701 in. Bore - 1.220 in. CH, 0.80 CC |
| Prop 65 Yes/No |
Yes |
| Title |
JE Pistons - Ford, Modular, 3.701 in. Bore, Piston |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
