As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Subaru EJ205 Stroker |
| Description_DEF |
Engine Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Subaru, EJ Series, 3.622 in. Bore, 9.50:1, Inverted Dome/Dish, Right Piston |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.622 Bore, 1.209 CD, 0.905 Pin, Set of 1. |
| Description_SHO |
Piston |
| Description_TLE |
Subaru EJ205, 92.00 Bore, Dish, Set of 1 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Add-On |
905-2250-18-51S |
| Add-On |
905-042-CT |
| Add-On |
JG1001-3622 |
| Bore Diameter |
92.00 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Make |
SUBARU |
| Compression Height |
1.209 |
| Industry |
Automotive |
| Engine |
EJ SERIES |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Cylinder Head |
EJ205 WRX |
| Engine - Web |
EJ Series |
| Piston Orientation |
Right |
| Piston Material |
2618 |
| Piston Quantity |
1 |
| Piston Volume |
-6.40 |
| Piston Pin Length |
2.250 |
| Piston Average Weight |
338 |
| Piston Pin Wall Thickness |
0.180 |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.905 |
| Piston Head Type |
Dish |
| Oil Ring Thickness |
0.111 |
| Out of Stock Message |
Call for Availability |
| Piston Series |
JE Pistons |
| Make - Web |
Subaru |
| Title |
JE Pistons - Subaru, EJ Series, 92.00 mm Bore, Piston |
| Prop 65 Yes/No |
Yes |
| Product Market |
Sport Compact |
| Product Type |
Engine Piston |
| Top Compression Ring Thickness |
0.0400 |
| Ringset Included |
Yes |
| Title - Web |
JE Pistons Subaru EJ Series Piston - 92.00 mm Bore - 1.209 in. CH, -6.40 CC |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Wall Thickness |
0.180 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.905 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
